Conductor | Insulation | Max.Cond Resistance( Ω/Km) | Permissible Ampacity 30 ℃(AMP ) | Package feet/coil Unit Length M (Ft ) | ||||
Seciton (mm2) | Construction ( No./mm ) | Diameter (mm) | Insulati on thlckne ss (mm) | Jacket Thickness (mm) | Diameter (mm) | |||
0.20 | 7/0.20 | 0.61 | 0.30 | 0.20 | 1.50 | 94.0 | 8 | (610)/(2000) |
19/0.12 | 0.60 | 0.30 | 0.20 | 1.50 | 94.0 | 8 | (610)/(2000) | |
40/0.08 | 0.5 | 0.30 | 0.20 | 1.50 | 94.0 | 8 | (610)/(2000) | |
0.30 | 7/0.254 | 0.77 | 0.30 | 0.20 | 1.70 | 65.3 | 10 | (610)/(2000) |
19/0.15 | 0.76 | 0.30 | 0.20 | 1.70 | 65.3 | 10 | (610)/(2000) | |
60/0.08 | 0.72 | 0.30 | 0.20 | 1.70 | 65.3 | 10 | (610)/(2000) | |
0.50 | 7/0.31 | 0.95 | 0.30 | 0.20 | 1.90 | 36.7 | 15 | (305)/(1 000) |
19/0.185 | 0.93 | 0.30 | 0.20 | 1.90 | 40.1 | 15 | (305)/( 1000) | |
0.75 | 1/1.0 | 1.00 | 0.30 | 0.20 | 2.10 | 24.8 | 20 | (305)/( 1000) |
7/037 | 1.13 | 0.30 | 0.20 | 2.10 | 24.8 | 20 | (305)/(1000) (305)/( 1000) | |
19/0.23 | 1.16 | 0.30 | 0.20 | 2.10 | 26.7 | 20 | ||
1.00 | 1/1.2 | 1.20 | 0.30 | 0.25 | 2.30 | 18.2 | 25 | (305)/( 1000) |
19/0.26 | 1.31 | 0.30 | 0.25 | 2.30 | 20.0 | 25 | (305)/( 1000) | |
1.25 | 19/0.30 | 1.51 | 0.30 | 0.25 | 2.50 | 14.6 | 32 | (305)/( 1000) |
1.50 | 19/0.32 | 1.61 | 0.30 | 0.25 | 2.60 | 13.7 | 38 | (305)/( 1000) |
2.00 | 19/0.37 | 1.86 | 0.30 | 0.25 | 3.06 | 9.0 | 45 | (200)/( 656) |
2.50 | 19/0 .41 | 2.06 | 0.30 | 0.25 | 3.26 | 8.2 | 50 | (200)/( 656) |
